Model
ESDAW-14CH

Item specifics

Color
White, black, grey
Compressor
Panosonic
Heat exchanger
High efficiency tube in shell
Throttling device
Electronica expansion valve
Controller
Lcd intelligent controller
Refrigerant
R407C/R410A
Custom color
Available
Sample
Available

Product review

Description

13~14kw green energy housing heating air source heat pump
Specification
Model  ESDAW-14CH (220v) ESDAW-14CH (380v)
Heating capacity  A7/W35 KW 13.2 13.7
Heating power input KW 3.8 3.9
Rated current A 17.3 7.4
COP A7/W35 / 3.47  3.51
Max. water temperature 60 60
Rated water temperature 55 55
Water flow m3/h 2.30  2.30
Water pressure drop Kpa 28  28
Water connections Inch 1" 1"
Compressor Brand Panosonic Panosonic
Qty 1 1
Power supply V/PH/Hz 220240/1/50 380400/3/50
Refrigerant /  R407c  R410a
Noise dB(A) 58 58
Net weight kg 128 128
Gross weight kg 143 143
Net dimensions mm 1110*460*1250 1110*460*1250
Packing dimensions mm 1220*480*1400 1220*480*1400
