55-80kw Heating and cooling commercial ground source heat pump for house heating
55-80kw Heating and cooling commercial ground source heat pump for house heating
55-80kw Heating and cooling commercial ground source heat pump for house heating
55-80kw Heating and cooling commercial ground source heat pump for house heating
Model
ESDWW-55C/68C/80C

Item specifics

Color
White, grey
Compressor
Copeland
Heat exchanger
Plate heat exchanger
Throttling device
Electronic expansion valve
Controller
Lcd intelligent controller
Refrigerant
R407c/R410a
Custom color
Available
Sample
Available

Product review

Description

55-80kw Heating and cooling commercial ground source heat pump

Specification
Model ESDWW-55C ESDWW-68C
Heating capacity W15/W35 KW 55 68
Heating power input KW 11 13.6
Rated current A 20.9 25.8
COP W15/W35 / 5 5
Max. water temperature 60  60
Rated water temperature 55  55
Water flow (hot water side) m3/h 7.5  13
Water flow (ground source side) m3/h 6.8  10.4
Water pressure drop Kpa 50  55
Noise dB(A) 45 55
Water connections Inch 2" 2"
Compressor Brand Copeland  Copeland
Quantity 2 2
Power supply V/Ph/Hz 380/3//50 380/3//50
Refrigerant / R410a R407c
Net weight kg 260 300
Gross weight kg 280 320
Net dimensions mm 708*1048*750 708*1048*750
Packing dimensions mm 755*1155*900 755*1155*900
